System Parameters
| Trigger Input Range | 1Hz~10 MHz |
| Max Trigger Clock | 100 MHz |
| Output Frequency Range | 1 Hz~1 MHz |
| Output Channels | 7 units |
| Delay Setting | Independent Delay Setting per Channel |
| Signal Transmission Mode | Channels 3-7 Support Burst & Continuous Output Modes |
| Jitter | ~100ps |
| Power Input | 24V, 2A |
| Output Interface | SMA |
| Software & Control | LabVIEW based & Communication Commands Included |
