Specifications
Laser Scanning Galvo Mirror Systems
| Laser input | Laser fiber optic input with an electrically controlled diaphragm system |
| Imaging range | 4096*4096 pix（Max） |
| Wavelength range | 400-900 nm |
Inverted microscope module
| Objectives | 100x, 50x, 10x air lenses (oil immersion lenses are selectable) |
| Spatial resolution | ≤260 nm |
Steady-state spectroscopy module
| Monochromator Focal length | 300 mm |
| Detector | PMT or CCD |
| Detectable Spectral range | 400-900 nm |
TCSPC module
| Time accuracy | 7 ps |
| Spectral range | 400-900 nm |
| Number of Bin channels | 4096 |
| Time window | 5 μs (expandable for long-lifetime testing) |
| Time resolution | ≤70 ps |
Selectable module
| Picosecond laser at 375/405/440/480/510/635/665/690/850/940/1060 nm |
| Picosecond super-continuum white light laser (410-2400 nm) |
